Fa2-Ultra Mini CNC Milling Center
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Features
•Three modes are available for selection, Fa2, Fa2-Pro, Fa2-Ultra
•5000 RPM high-speed machining for smooth surface
•2 station ATC for quick tool change
•Inner structure of milling center
•Well-organized accessories
Specifications
| Table | Table size | 230*100 mm |
| T slot (amount*width*distance) | 7*6*14 mm | |
| Max. load | 5 kg | |
| Travle | X travel | 285 mm |
| Y travel | 125 mm | |
| Z travle | 130 mm | |
| Spindle nose to table | 55-185 mm | |
| Spindle | Spindle taper | ISO15 |
| Spindle motor | 250 W | |
| Spindle speed | 5000 r/min | |
| Feed | Rapid feed | 2 m/min |
| Power of X/Z | 1.3 Nm | |
| Power of Y | 0.6 Nm | |
| Tool changer | Tool number | 2 |
| Max. tool diameter | 10 mm | |
| Max. tool length | 0.1 kg | |
| Max. tool weight | 60 mm | |
| Time of tool changing | 15 sec | |
| Accuracy | Positioning accuracy | 0.02 mm |
| Repeatability accuracy | 0.01 mm | |
| Others | Pneumatic supply | 0.4 Mpa |
| Weight | 165 kg | |
| Power | 0.8 kva | |
| Overall dimension | 1600*900*1400 mm | |
| Packing size | 1760*1000*1600 mm |
