ECO1 5-axis Milling Machine

description1

Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Features

•Support 5-axis linkage interpolation;
•Support RTCP function and 3+2 function;
•Support absolute value encoder function (without installing origin switch);
•Support encoder feedback and grating ruler feedback;
•Compensation for pitch error;
•Add dual speed forward function;
•Support stl 3D graphic processing preview;
•Support the function of cutting off, power-off, and continuous connection, as well as skip segment processing;
•Directly compatible with processing programs from SIEMENS, HEIDEN-HAIN, FANUC, SYNTEC, GSK, and HNC systems;

Specifications

Table	Table size	φ130 mm
Table	Max load	10 kg
Travel	X travel	300 mm
	Y travel	320 mm
	Z travel	300 mm
	A swing angle	-90°～+120°
	C swing angle	360°
	Working area	φ100x120 mm
Spindle	Spindle taper	ER11
	Spindle speed	24000 r/min
	Spindle power	1.5 Kw
Axis	X/Y/Z speed	5 m/min
	A swing speed	20 rpm
	C swing speed	20 rpm
	X/Y/Z motor	3 Nm
	A/C motor	2.2 Nm
Accuracy	X/Y/Z positioning accuracy	0.015 mm
	A/C positioning accuracy	30 sec
	X/Y/Z repeatability accuracy	0.01 mm
	A/C repeatability accuracy	20 sec
Others	Pneumatic supply	N/A
	Power	3 KVA
	Machine weight	520 kg
	Overall dimension	1600x960x2000 mm
	Packaging size	1710x1310x2220 mm
