C2L Mini Lathe
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Features
• Constructed with cast iron giving great rigidity
• Precision ground Vee bed slide ways
• Fully featured saddle and carriage assembly including powered lead screw
• 500W motor with variable speed and a 2 speed gearbox
• Change wheel set providing thread cutting selections between 0.4-2.0mm & 12-52 tpi
Specifications
|
Swing over bed |
180 mm |
|
Distance between centers |
300 mm |
|
Hole through spindle |
25 mm |
|
3-jaw chuck diameter |
100 mm |
|
Cross slide travel |
65 mm |
|
Compound travel |
55 mm |
|
Spindle taper |
MT3 |
|
Tailstock taper |
MT2 |
|
Spindle speed |
50-2500 ±10% rpm |
|
Motor output power |
500 W |
|
Range of threads Metric version |
0.4-2.0 mm (10 thread pitches) |
|
Imperial version |
12-52 TPI (18 thread pitches) |
|
Overall dimension(LxWxH) |
800x300x300 mm |
|
Weight(Net/Gross) |
44/50 kg |
