X6 Bench Mill Drill
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Features
•Milling, drilling, tapping, reaming, boring
•Spindle box can rotate and tilt
•Spindle micro feed (automatic feed is optional)
•Supporting spindle with strong high load tapered bearing
The spindle can be locked and the head can be
•Elevated and lowered electronically
•Adjustment of workbench gap insert
•Limited position of workable is adjustable
•Gear gearbox drive
•Accurate positioning, strong rigidity and high cutting force
Specifications
|
Drilling capacity (Iron/Steel)
|
40/32 mm
|
|
End mill capacity
|
32 mm
|
|
Face mill capacity
|
76 mm
|
|
Longitudinal travel (X)
|
500 mm
|
|
Cross travel (Y)
|
210 mm
|
|
Spindle travel
|
120 mm
|
|
Spindle taper
|
MT3 or R8
|
|
Spindle speed
|
75,170,280,540,960,1600 rpm
|
|
Table effective size
|
730 x 210 mm
|
|
Max. distance spindle to table
|
450 mm
|
|
Column tilting angle
|
45°L, 45°R
|
|
Motor output power
|
1500W
|
|
Packing size (LxWxH)
|
870 x 760 x 1150 mm
|
|
Weight (Net/Gross)
|
285/315kg
|
