X2.3 Bench Mill Drill
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Features
• Speed digital display
• Feeding depth readout
• Emergency stop switch
• Chuck guard and dust cover
• Fine feeding function
• Solid column
Specifications
|
Max. Drilling capacity |
25 mm |
|
End mill capacity |
16 mm |
|
Face mill capacity |
50 mm |
|
Spindle taper |
MT3 |
|
Spindle sleeve travel |
50 mm |
|
Table size |
500*180 mm |
|
Longitudinal axis (X) |
290 mm |
|
Cross axis (Y) |
180 mm |
|
Headstock travel (Z) |
280 mm |
|
Variable spindle speed |
100-3000 rpm |
|
Max distance spindle to table |
370 mm |
|
Swivel angle of milling head |
±90° |
|
Distance from spindle axis to column |
200 mm |
|
Distance from spindle to table surface |
300 mm |
|
Motor power |
750W |
|
Overall dimension (LxWxH) |
750x500x760 mm |
|
Packing size (LxWxH) |
670x550x860 mm |
|
Weight (Net/Gross) |
110/135 kg |
Review
Standard attachment
• Φ13 mm Drill chuck
• Wrench set
• Oil can
