SX35 Bench Mill Drill-LED Mirror Display
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Features
•Based on SX3.5
•Variable spindle speed
•Feeding depth and spindle speed digital readout
•Tapping function
•Brushless DC motor
•Fine feeding function
•Large worktable
•Magentic suction tool zone
•Z Axis Lift Press Button To Adjust
Specifications
|
Drilling capacity
|
30 mm
|
|
Max.taping capacity
|
12 mm
|
|
Spindle taper
|
MT3 or R8
|
|
Longitudinal travel (X)
|
500 mm
|
|
Cross travel (Y)
|
210 mm
|
|
Headstock travel (Z)
|
250 mm with chuck guard
|
|
Spindle stroke
|
78 mm
|
|
Max. distance spindle to table
|
370 mm /MT3
|
|
Table effective size
|
740 x 180 mm
|
|
T-slot size
|
12 mm
|
|
Motor output power (Brushless DC motor)
|
1000W
|
|
Spindle speed Low range
|
80-1500 rpm±10%
|
|
Spindle speed High range
|
280-5000 rpm±10%
|
|
Overall dimension (LxWxH)
|
950 x 770 x 920 mm
|
|
Packing size (LxWxH)
|
1100 x 920 x 990 mm
|
|
Weight (Net/Gross)
|
145/175kg
|
